VINE AND TREES PLANTER WAGNER

Rebholzzieher KOBOLD shows this year in a new design with technical innovations.

In the modification, which was tested in summer in South Africa in continuous use, the replacement of the two finger feeders with a spider wheel proved to be particularly successful. With this design, the yarn is constantly kept under the fingers and does not reach the tires. Continuous and careful use of labor significantly increases productivity. But also the new feeder and the best working speed adjustment of the spider wheel are the reason for an optimized work result.

Tested and tested components such as forage harvester, side tilt ATLAS mast, hydr. Transverse adjustment, hydr. Angle adjustment of work head and drawing system.

Your advantages:

- Prevention of wire tears by the new spider wheel

- The wires should neither be tensioned nor stored

- Improved feed of the vine wood

In the crusher version, the hydraulic unit is standard equipment.
Connection requirements: Two oil circuits are required.

Permanent oil circuit with at least 60 liters permanently in a single action control unit, which drives the wheels, the wheels of the fingers and the crusher (35 liters without crusher). Alternatively, we offer depending on the design of a corresponding hydraulic unit. The speed of the finger wheels is adjustable from the tractor.
The secondary oil circuit provides up to three dual-action control units, eg mast adjustment, side tilt, hydraulic transverse adjustment.
